Dynamic 3D Imaging Technology / Power Lift / Dual Screen / Wheel Alignment With Tool Cabinet

Model: Aver V3D-KL

Categories Products, Wheel Alignments

Description

Aver-801 Rim-Lock Tire Changer is exactly what you’re looking for, reliability, dependability and durability at a reasonable price. This deluxe tire changer comes fully equipped with every feature and accessory your business needs to excel. Every feature has been engineered to enhance workflow.

Our semi-automatic swing arm assist easily adjusts so the mount/demount tool is properly fixed to the rim, allowing technicians to change difficult wheel applications, such as low-profile wheels and run-flat tires quickly and efficiently. The built-in bead sealing jets seal beads quickly. Tabletop inflation provides quick and efficient workflow. Conveniently placed foot pedals allow for instinctive movements while mounting and demounting tires, providing precise control over every step of the changing process.

The Aver-801 Rim-Lock Tire Changer features a compact cabinet and required workspace allowing it to easily fit into limited space applications without sacrificing capability.

Features

• Economically applicable type.
• The large cylinder piston is made of high-density die cast aluminum, which is used to make the large cylinder
service life.
• The claw is made of precision cast steel material, which is durable.

• It can be optionally equipped with motorcycle specific fixtures.
• The enhanced internal box structure reduces the elastic deformation of the machine during use and extends the service life of the equipment.
• The working disc claw is equipped with a protective cover to provide more comprehensive protection for the tire and wheel rim.
• Universal shovel, more suitable for tire scraping operation.
• Iron stamped foot pedals, durable for life (aluminum feet can be optionally selected)
Step on).
• Adjust the position of the small boat to change the range of the clamping wheel

Specification

Measuring Project	Accuracy of measurement	Measuring range
Display precision	0.1mm/0.01°	——
Toe	±0.01°	±40°
Camber	±0.02°	±45°
Caster	±0.02°	±45°
S.A.I	±0.02°	±45°
Set back	±0.02°	±40°
Steering angle	±0.02°	±45°
Thrust angle	±0.01°	±40°
Track width	±2mm	1219mm-2438mm
Wheelbase	±2mm	2006mm-4572mm
